双线传输线

  • two-wire line
双线传输线双线传输线
  1. 矩形截面带状双线传输线特性阻抗分析

    Analysis of characteristic impedance of strip double line

  2. 非对称平行双线传输线单位长度电容的精确计算

    The Exact Calculation of the Capacity of Unit Length of the Asymmetric Ribbon Type Feeder Transmission Line

  3. 采用印制在介质板双面的平行双线传输线对天线阵列进行馈电,输入端使用渐变传输线进行阻抗匹配。

    The parallel double transmission line , printed on the both sides of the substrate is utilized as feed line , and a tapered transmission line is employed for impedance matching .

  4. 该文在假设双线传输线两线上电流大小相等、方向相反的条件下,运用双线传输线理论思想,推得不对称(电流)双线均匀传输线的电压、电流关系。

    In this paper , by supposing the currents on the two lines are equal but opposite and with the application of bifilar transmission-line theory , the current-voltage relationships of the asymmetrical ( current ) bifilar even transmission line are obtained .

  5. 本文应用运算微积法研究任意形状信号激励下的双线均匀传输线,同时用FORTRAN77语言编写了史密斯圆图的计算机程序。

    In this paper , we study two-conductor uniform transmission lines which are excited by arbitrarily-shaped signals in terms of the operational calculus method , and write a computer program for Smith chart with FORTRAN 77 .

  6. 同轴双线型加载传输线特性阻抗的计算

    Determination of the Characteristic Impedance of Coaxial Hybrid Loaded Transmission Line
