矫直机

冷矫直机就是重要的轧机辅助设备之一。

Cold plate leveler ( CPL ) is one of the important mill auxiliaryequipment .

复合材料层合板的铺层优化分析及拉伸-弯曲耦合刚度的影响拉伸弯曲矫直机的应用

On Optimum Design of Laminated Plates and the Effect of Coupling between Bending and Extension THE APPLICATION OF TENSION LEVELER

调整矫直机直到线圈末端拉平。

Adjust flattener until the coil ends are leveled and flat .

H型钢梁矫直机设计制造

Design and Manufacture of Straightener for H Type Steel Beam

基于MATLAB的精密矫直机位置伺服系统的研究

Study on the Location Servo System of the Precision Straightening Machine Based on MATLAB

矫直机PLC控制系统设计

The Design of PLC Control System for Straightener

本文介绍了矫直机PLC自动控制系统的组成，并详细分析了矫直机的工作原理和工作过程。

This paper introduces the configuration of the PLC auto control system of straightening machine , and analyzes operating principle and working process in detail .

采用某厂九辊悬臂式变辊距矫直机的工艺参数，建立了H型钢矫直过程的三维动态有限元仿真模型。

The3-D finite element model of an H-beam in straightening process was established by using the processing parameters of a nine-roller cantilever straightener with variable roller spacing .

第五章首先讲述了液压矫直机控制系统的PLC软件编程，包括程序流程图，触摸屏界面设计和一些编程中具体的实现细节。

Chapter five is concentrated on PLC software program of control system , including flow chart , interface design about the touch panel and some program details .

简要介绍了莱钢大H型钢轧线矫直机的工艺流程，重点介绍了大H型钢矫直机主要的控制模型。

This paper briefly introduces the technological flow of the straightener in Laiwu Steel Group 's heavy H-beam mill and emphatically describes the main control model of the straightener .

阐述了用PLC、变频器、编码器组成的一个具有操作站可实现工艺要求的矫直机控制系统的原理、硬件设计、软件编程。

The principle , hardware design , and software process of straightener control system have been made up with PLC , frequency converter as well as encoder composition which can realize technology requirement of operating station .

进口3000t液压矫直机液压缸密封装置的改进

Improvement of Sealing Arrangement of Hydraulic Cylinder for Imported 3000t Hydraulic Stretcher

最后通过建模分析了全液压矫直机的PID控制参数的优化过程，通过优化得到一些具有参考价值的PID控制参数。

Finally , through the adoption of modeling and analysis of the hydraulic straightening machine PID control parameters of the optimization process , by optimizing we get some with a reference value of PID control parameters .

介绍了HERRVOSS精密辊式矫直机的工作原理、特点及辊系结构。

The work principle , characteristics and roll structure of HERR-VOSS precision roll leveller are introduced .

交-直-交变频调速系统在鞍钢大型厂50m重轨矫直机主传动辊上的应用

Application of AC-DC-AC Frequency Control System of Motor Speed in Main Drive Rolls of 50m Heavy Rail Leveller in AISC Heavy Section Plant

PCY恒压变量泵液压系统四对轧辊缸动矫直机泵站的设计

Design of pump station with PCY constant pressure variable pump for hydraulic four-pair-roller straightening machine

3800mm宽厚板矫直机结构设计及关键构件的力学分析

Structure design of 3800 wide heavy plate leveler and the mechanical analysis of key components based on FEM

为了保证钢板的平直度，冷矫直机是厚板厂后区必不可少的设备。由于采用了西门子公司的SimaticTDC控制技术，可以很好地实现控制功能和完成控制任务。

In the heavy plate mill , cold plate leveler play an important role in the finishing area , and Simatic TDC ( technology drive control ) control technical of Siemens in Germany are used , which can fulfil control function and task .

六辊矫直机矫直钢管管端的理论研究

A theoretic study concerning end-straightening of steel tube with 6-high straightener

矫直机矫直辊设计分析

The Design and Analysis of Rollers of the Six-Roller Straightening Machine

复合重轨矫直机的矫直力计算

Calculation of force of compound roll straighten device of heavy rail

回转式薄壁钢管矫直机传动功率计算

Calculating Formula of the Transmitted Power of Thin Wall-Tube Rotary Straightener

钻铤套管和钻杆压力矫直机的设计

Design of the straightening machine for collars casings and drill pipes

高强度冷矫直机机架结构优化分析

Structure Optimization Analysis for Housing of High Strength Cold Straightening Machine

强力矫直机液压管路冲洗方案的优化设计

Optimun design of the hydraulic pipe flushing plan of hot leveller

轴类零件矫直机在线测控系统

Measurement and Control System for a Straightening Machine of Shaft Parts

二辊矫直机辊形参数设计

Research of the roll shape parameters design in tow roll straightener

基于频谱分析的矫直机齿轮箱故障诊断

Fault diagnosis of gear case based on analysis of spectrum

锚杆杆体矫直机的研制

Development of straightening machine using in the mine 's bolt-rod

矩形钢管矫直机的设计与分析

Design and Analysis of straightening machine for Rectangular Steel Pipes
