静电放电发生器

详细设计了静电放电发生器的软件，分别介绍了单片机程序与主机程序的设计方法，并给出了主要的工作流程。

Detailed software design of ESD is given . We introduce the design methods of microcontroller and host computer programs . Otherwise , main workflows is given . 4 . ESD generator developed is tested .

对开发的静电放电发生器进行了测试，实测了HBM、MM、BMM的电流，并给出了实测波形。最后对本文全部工作进行总结，也对今后进一步研究方向做了分析与展望。

Currents of HBM , MM , BMM are tested and measured waveforms are given . Finally , contributions of this work is summarized , and further works are analysed and prospected .

结果表明，静电放电发生器中电阻和连接线长度影响电流波形的上升时间；连接线的布置影响着电流波形的平滑性；不同的终端负载也对电流峰值有很大影响。

The result indicates that the lengths of the resistor and connection wire affect the rise time of the ESD current ; the disposition of the connection wire influences the smooth of the current and the termination resistance affects the peak value of the current .

为研究智能电器监控单元的静电放电敏感性，利用静电放电发生器对设备机壳放电进行了实验研究。

The electrostatic susceptibility of digital relay was experimentally studied through discharging to the shell by the electrostatic discharge ( ESD ) generator .
