G02
-
Correct application of G02 ( G03 ) code in the programming of CNC machine tool
G02(G03)代码在数控车床编程中的正确应用
-
It takes the command of G02 as an example , offers the syntax of APT and coordinates formula for transforming .
其中重点介绍了顺时针圆弧插补指令G02的转换方法,给出了相应的APT语句格式和坐标转换公式。
-
When CNC G code is used in the CNC lathe programming , using G02 ( G03 ) out of the way easily causes the programming error .
当采用数控编程G代码编制数控车床加工程序时,容易出现G02(G03)代码使用不当而造成编程错误。
-
This paper discusses how to understand the definition of G02 ( G03 ) code and use G02 ( G03 ) to program correctly .
本文论述了如何正确理解G02(G03)代码的定义,从而保证正确使用G02(G03)代码编制数控加工程序。
-
This program includes G03 instruction in G17 plane , G02 order in G18 plane , alternately milling in G17 plane and G18 plane .
该方法通过在G17平面内用G03指令,G18平面内用G02指令,在G17和G18平面内交替铣削,实现了加工要求。
-
This paper , basing on some professional standards related with G code and Cartesian coordinatesrule , expatiatesonthe definition and proper use of G02 ( G03 ) instruction codein CNC lathe .
本文基于G代码有关标准及迪卡尔坐标原则,并以数控车床为例,阐述了G02(G03)代码的严格定义及正确应用。
