磁控管

磁控管H形输出变换器长度的探讨

An investigation on the length of h-section-guided output transformer of a magnetron

文中提出了一种以DSP为控制部分的多磁控管微波输出系统。

This paper presents a DSP system to control the multiple magnetron microwave output .

铁氧体构成磁控管的磁场分析及它对PET表面改性的影响

Analysis of Ferrite Magnetic Field and Its Effect on Surface Modification of PET by Fluorocarbon Plasmas

微波-ECR等离子体增强非平衡磁控溅射技术及CN薄膜的制备研究磁控管总体设计的探讨

MW-ECR Plasma Enhanced Unbalance Magnetron Sputtering and Carbon Nitride Films Preparation Study of the Magnetron Design

系统采用DSP技术、可控硅技术以及微波理论，通过控制磁控管阳极电流来控制各磁控管微波功率的变化。

The system adopts DSP technique , controllable silicon technology and microwave theory , it controls the magnetron microwave power change by controlling the magnetron anode current .

紧凑型强流ECR源介绍ECR型离子源的磁控管稳流电源。

A stable power supply for magnetron of microwave ion source is described .

A6磁控管谐振系统的计算与模拟分析

Calculation and simulation analysis of A6 relativistic magnetron 's resonated system

A6相对论磁控管谐振系统研究

Study of Resonant Systems of A6 Relativistic Magnetrons

最近几年，轴向输出相对论磁控管（MDO）得到了较多的研究。

In recent years , the relativistic magnetron with diffraction output ( MDO ) has been studied rapidly .

本文利用二端网络理论，推出了磁控管谐振点驻波导数与H形输出变换器截止波长之间的关系式。

In this article , 2-terminal network theory is applied to deduce a formula of the relationship between the standing-wave , ratio at the resonance point of a magnetron and the cutoff wavelength of an H-section-guided output transformer .

与95%Al2O3瓷的铜封件具有良好的气密性、抗热冲击性能和高的封接强度，能够满足磁控管、行波管等制造要求。

The alloy-95 % Al_2O_3 ceramic seals using oxygen-free copper as solder possess with high sealing strength , good tightness and spelling resistance , and are sufficient for making magnetron , TWT , etc.

文章就微波炉和磁控管的相关设计与EMI测试关系进行了讨论，在成本和测试效果之间找到了平衡点。

This article discussed about the relation of the interrelated design of magnetron and microwave oven and EMI test , and tries to find a balance point between cost and test .

PercySpencer是一个物理学家，在二战期间从事雷达的研究工作，他注意到磁控管融化了他的巧克力。

Percy Spencer was a physicist working on radar during World War II , when he noticed the magnetron was melting his chocolate bar .

应用定K型滤波器模型理论对现有的磁控管滤波组件进行分析，反推出该滤波组件的截止频率和设计特性阻抗，该类参数在日后的新型滤波组件设计过程中有重要参考价值。

Applied constant K type filter model on the existing magnetron filter , the cut-off frequency and the designed characteristic impedance of the filter were derived . Those parameters have important reference value for a new type filter design process in the future .

医用驻波电子直线加速器中磁控管的谐振频率fM和加速管的固有频率fo之差Δf对加速器的主要物理指标，如射线能量，剂量率及其稳定性等起着直接的影响。

The frequency difference , Δ f , between the resonant frequency , f_Moof magnetron and the proper frequency of accelerating tube influences directly the main physics indexes such as X-ray energy and dose rate of the medical standing wave linear electron accelerator .

以此为基础，作者从不同的角度提出了三种改善相对论磁控管效率方案：①降低有载Q值；②限制工作电流；③高阻相对论磁控管锁相阵列。

Based on this , the author proposes three ways to improve the efficiency of relativistic magnetron from different perspectives : ① lower the load Q value ; ② set an upper limit to work current ; ③ array of relativistic magnetron with high impedance .

利用等效电路法和高频分析软件（HFSS）对A6相对论磁控管谐振系统进行了理论计算与模拟分析，着重考虑了相对论磁控管端帽的引入对谐振频率的影响。

A6 relativistic magnetron resonant system is calculated and simulated by equivalent circuit and high frequency structure simulator ( HFSS of agilent ), and the effect of end cap to resonant frequency is especially presented in this paper .

结果：淫羊藿苷的最佳工艺条件是微波辅助辐射时间助提取时间1.5h，液固比2000/15，磁控管阳极电流0.7A。

RESULTS : The optimal strategy met the extraction conditions of permatron anodic current 0.7A , the ratio of liquid to solid 2000 / 15 and microwave assisted irradiation time 1.5A .

本文分析了医用直线加速器M5193型磁控管产生异常打火的原因、处理办法及由此引发特殊故障的应急处理。

This article analyzes the causes of abnormal spark of M5193 magnetron of BJ-6B medical linear accelerator and provides the emergency measures .

先通过微波工作室CST软件仿真计算，并结合波导设计理论对某公司原有辐射器结构进行场分析，然后对磁控管的安装位置与辐射器结构进行了优化设计。

First the precision model of radiation device in a microwave heater was simulated by CST Microwave Studio and the electrical fields were analyzed with the design theory of waveguide . Then the fixing position of magnetron and the structure of radiation device were optimized .

介绍了先通过Magic-3D软件仿真计算，然后根据仿真所得到的结论，利用样管实验所研制的一款新磁控管。

The purpose of this paper is to introduce a new microwave oven magnetron which was developed by simulation using Magic-3D software and sample experiments .

碳化La2O3Mo阴极的微波能量输出功率为500W，而同类型的碳化ThO2W阴极磁控管的额定微波能量输出为900W。

Compared to 900 ? W microwave energy output of same type carbonized ThO 2 W cathode magnetron , only 500 ? W microwave output can be acquired for carbonized La 2O 3 Mo cathode .

运用低成本的微波炉磁控管，在KT-5C托卡马克装置上设计和安装了水平和垂直两套2.45GHz/3Kw的电子回旋波发射系统。

Using low cost , commercially available oven magnetron as the source of the wave power , Two set of 2.45GHz/3Kw micro wave injection system were set up in the KT-5C tokamak .

计算机模拟结果证实，该方法可使以磁控管为发射机的MTI雷达的改善因子由目前的20dB左右提高到50dB左右。

Its limiting performance is also discussed . Computer simulation shows that the improvement factor of MTI radar system with magnetron as transmitting tube can be increased from 20 dB to 50 dB or so by this method .

端部空间对磁控管系统谐振特性的影响

The Effects of the End - Space on Magnetron Resonant System

同轴磁控管抑制干扰模式的新方法

A New Way to Repress the Jamming Mode in Coaxial Magnetron

无油超高真空排气对磁控管性能的改善

Improvement of oil - free ultrahigh vacuum on charateristics of magnetrons

优化极靴的微波炉磁控管磁场分析

Analysis of the Magnetic Circuit with Short Poles in Oven Magnetron

某型导弹雷达通用磁控管自动老炼仪的设计

Design of the General Automatic Magnetron Ager for Terminal Guidance Radar

微波加热器磁控管电源的研究与设计

Study and Design of Magnetron Power Source in Microwave Heating Equipment
