成形模具

  • 网络Forming die;forming mold
成形模具成形模具
  1. 成形模具在1次冲压过程中先后完成弯曲和翻边。

    The forming die could finish bending and flanging separately in one stamp .

  2. 对该生产线的主要工艺技术作了分析说明,给出了工步图与成形模具图。

    The process flow diagram of crankshaft forging and the forming die diagram are also shown in the paper .

  3. 汽车地毯成形模具CAD技术已开发成功,能够根据客户需要,生产新车型的轿车地毯。

    By the development of GAD on shaping mould of car carpet , the new type car carpet could be manufactured according to customers ' demands .

  4. Ni-Ti形状记忆合金骨卡环热成形模具设计

    Hot Forming Mould Desing for Keeper of Ni-Ti Memory Alloy

  5. 基于Solidworks三维平台,采用Access,SqlServer及VB编程语言,通过调用SolidWorks的API应用编程接口进行客车件冲压成形模具软件系统的设计和开发。

    3D forming die design system is designed by using Access , Sql Server , VB programming language and calling API of Solidworks on the platform of Solidworks .

  6. 基于Laplace传热理论,建立了模压成形模具的三维稳态仿真模型以及制品的一维瞬态仿真模型。

    The three dimensional steady numerical simulation model of the mold and the one-dimensional transient simulation model of the nonwoven composite part were built up based on Laplace theory .

  7. 提出并实现了以快速原型(RP)技术和电弧喷涂技术(AMS)为核心的板料成形模具快速制造新工艺。

    A rapid manufacturing process for sheet metal stamping with RP and arc spraying metal ( AMS ) as its key technologies , namely RP-AMS process , is developed .

  8. 10in不锈钢肘管冷成形模具及工艺分析

    Analysis of 10-inch diameter stainless elbow tooling and cold forming process

  9. 通过对火车轮成形模具设计方法的研究和火车轮成形过程的有限元分析,开发出一套适用于火车轮锻轧生产工艺的车轮模具设计CAD系统。

    Based on the die design method researching and FEA for rail wheel forming , a CAD system for designing rail wheel forming dies is described in this paper . The CAD system can be applied to the production of rail wheel with forging-rolling method .

  10. 利用DYNAFORM软件实现了深拉伸件成形模具模面的快速设计以及利用其数据共享的特性介绍了采用Pro/E进行模具成形零件的数控编程的过程。

    The quick design of deep drawing parts forming die surface is realized by DYNAFORM software , and NC program process of die forming parts using Pro / E is introduced by sharing database .

  11. 运用有限元法对太阳电池硅片电磁悬浮熔炼离心铸造(ELCC)技术中成形模具的稳态温度场进行了计算机模拟。

    Omputer simulation of the temperature field of the mold , which is used for producing the low cost solar cell silicon sheet with the Electromagnetic Levitation-melt Centrifugal Casting ( ELCC ) technology , is carried out with the finit element method .

  12. 耐火砖成形模具材质探讨和初步研制

    The Material Investigation of the Refractory Model and Its Preliminary Manufacture

  13. 盖板成形模具的设计制造

    Design and Manufacture of the Die for Forming the Cover Plate

  14. 直纹滚花螺母冷挤压一次成形模具

    Cold Extrusion Die for Straight Knurl Nut in a Single Process

  15. 粉末冶金高强度锥齿轮成形模具结构

    Structure of forming die for preparing high strength PM bevel gears

  16. 内燃机用螺栓保护螺母温挤压成形模具设计

    Design of Warm Extruding-Forming Die for the Nut-Protected Bolt in Gas Engine

  17. 螺旋管成形模具的CAD/CAM方法研究

    CAD / CAM Method Research of Helix Pipe Molding Mould

  18. 新型结构异型管材成形模具

    A new type of construction mold in taking shape of unusual tube

  19. 粉末冶金齿轮成形模具数控线切割加工仿真

    NC wire-cutting simulation of die machining for powder metallurgy gear

  20. 电源插座压制成形模具的设计

    Design of Compression Mold for the Power Supply Plug-in Socket

  21. 拖拉机弹簧座成形模具设计及仿真分析

    Die Design and Simulation Analysis of Spring Block in Tractor

  22. 摩托车油箱液压成形模具及其液压控制系统的设计与开发

    Hydroforming Mould and Hydraulic Control System for Motorcycle Oil Box

  23. 一种多平行小孔件的成形模具设计

    Design of die for forming p / m part with multi-parallel holes

  24. 精密成形模具材料热处理工艺研究

    Research on Process Testing of Heat Treatment for Precision Forming Die Materials

  25. 接插件冷挤压成形模具的研制与设计

    Research and design on cold extrusion forming die of plug

  26. 金属粉末件钢模压制成形模具设计计算方法

    Design and construction of the die for metal powder compaction

  27. 温塑性成形模具润滑研究

    The Research of Mould Lubrication for Warm - Plastic Forming

  28. 钎头温挤成形模具的破坏形式分析

    Analysis of Fracture Form for Bore Bit Warm Extrusion

  29. 手机锂电池不锈钢外壳成形模具设计

    Design Of the Die for Forming the Stainless-Steel Shells Of Mobile-Phone Li Batteries

  30. 星形套冷挤压成形模具结构分析及优化

    Structural analysis and optimization of the cold extrusion mould of star sleeve workpiece
