折射系统
- Refractive system;【机】dioptric system
-
最后,我们谈谈舒曼的medial反折射系统。
Finally , we mention the catadioptric system of schupmann 's medial .
-
设计的折射系统和折衍混合系统的镜头直径分别为28mm和22.4mm,重量分别只有33g和11.9g,且最大畸变分别为3.2%和0.17%,分辨率满足SXGA显示模式。
The refractive projection system has a 28 mm diameter and 33 g weight . And the hybrid refractive-diffractive system has a 22.4 mm diameter and 11.9 g weight only . The maximum distortions of the two systems are less than 3.2 % and 0.17 % , respectively .
-
球面折射系统和复合厚透镜的分数傅里叶变换
Fractional Fourier transform of spherical refracting system and compound thick lens
-
失调单球面折射系统的衍射积分和分数傅里叶变换
The Diffraction Integral and Fractional Fourier Transform of Misaligned Single Spherical Refracting System
-
重焦折射系统的成像
The imaging of a refraction system with overlapping focus
-
提出单球面折射系统可以作为光学分数傅里叶变换的最基本单元。
Single spherical refracting system as the most basic unit for performing fractional Fourier transform was proposed .
-
本文用矩阵处理球面折射系统光学问题来介绍矩阵方法在几何光学中的应用。
We introduce the application of matrix method in geometrical optics by dealing spherical refraction system with matrix method .
-
山基GPS掩星反演大气对流层折射率系统组成及其程序实现
System and Software Performance of the Atmospheric Refractive Inversion for Mountain-based GPS Occultation
-
与其它误差源相比,固有圆双折射对系统误差影响较小;
Compared with the other error factors , the effect of the intrinsiccircular birefringence is relatively small .
-
在薄透镜焦距测定实验的基础上,进一步讨论了折射反射系统成像的规律。
On the basis of thin-lens focal length measurement experiment , the imaging law of refraction-reflection system was further studied .
-
分析了光纤中线性双折射对系统性能的影响以及解决的方法。
The influence on all-fiber current transducer of linear birefringence in optical fiber is analyzed and partial resolvents are concluded in this part too .
-
由此提出增加入射光相移来减小初始线性双折射对系统输出影响的方法。
A method of reducing the influence of passive OCT initial linear birefringence is proposed based on increasing the phase shift of incident light .
-
根据球面的几何特征,分析了单球面折射光学系统折射面倾斜和偏心时的失调特征;
According to geometric feature of spherical surface , the misalignment characteristics of single spherical refracting system when the refracting surface was tilted and decentered were analyzed .
-
将计算光学系统各个折射面对系统像差贡献的理论应用于人眼中。
The theory of computing the contributions of each refractive surface of the optical system to total aberrations was applied to the human eye model for the first time .
-
分析结果表明:当温度在-40℃&40℃范围内变化时,线性双折射使系统灵敏度的变化可达1%;
The outcomes show that the system sensitivity can be changed by one percent when the ambient temperature varies in the range from negative 40 degrees to positive 40 degrees .
-
由失调元件矩阵和共轴元件矩阵的依次相乘,得到了完备的描述失调单球面折射光学系统的矩阵;
From the principle of ordered multiplication of matrix of on-axis element and matrix of decentered element , the strict matrix which described the misaligned single spherical refracting system were presented .
-
本文以高速光纤通信系统为背景,首先研究了啁啾类孤子对在非均匀光纤放大器的传输特性;其次,求解了双折射光纤系统中矢量亮孤子的精确解。
Based on high-speed fiber communications systems , first , we research transmission characteristics of chirped soliton pairs . Then , we give the precise bright soliton solution of vector soliton in birefringence fiber model system and find that the soliton solution is stable .
-
从系统衍射积分与失调矩阵元的关系导出了该系统的失调衍射积分,并利用单球面折射光学系统的分数傅里叶变换结构参数得到了系统失调时的分数傅里叶变换结果。
With the relation between system diffraction integral and the misaligned matrix element , the diffraction integral of the misaligned system was derived . Based on the structure parameters of fractional Fourier transform of single spherical refracting system , the misaligned fractional Fourier transform was also obtained .
-
首次采用P-W-C法求解衍/折射薄透镜系统的初级像差方程。
The primary aberration equation of the diffractive / refractive hybrid thin lens system is solved by the method of P-W-C firstly .
-
谐衍射/折射双波段系统设计
The Dual Band Design of Harmonic Diffractive - Refractive Optics System
-
一个透镜是包含两个折射面的光学系统。
A lens is an optical system including two refracting surfaces .
-
结构型式对折射式光学系统二级光谱的影响
The structure effect on the secondary spectrum of long focal refractive optical system
-
参量型空气折射率传感系统
A parametric type transducing system for air refractive index
-
快速折射红外光学系统
Fast refractive infrared optical system
-
基于双折射原理共焦系统超分辨性能及轴向扫描技术研究
The Research on the Superresolution of the Confocal System and Its Axis Scanning Technology Based on Birefringent Theory
-
二次成像中波红外折射衍射光学系统设计梯度透镜折射率分布高次项系数的数值计算
Design of Re-imaging MIR Optical System Employing Refractive and Diffractive Optical Elements NUMERICAL CALCULATION OF HIGH ORDER ABERRATION COEFFICIENTS OF RADIAL GRIN LENS
-
目前,折射式光学系统的二级光谱校正还存在很大问题,特别是红外光学系统,红外材料本来就很少,又缺少特种材料。
At present , correcting secondary spectrum of refractive optical system is a problem , especially in infrared optical system . Because of the short of infrared material and lack of particular material with correcting secondary spectrum .
-
当温度均匀分布,且不考虑残余应力的温度特性时,传感头与周围介质相互作用产生的应力线性双折射是影响系统灵敏度的主要因素。
When temperature field distributes evenly , and the temperature characteristics of residual stress are ignored , then the linear birefringence induced by mutual pressure between sensing head and surrounding material is the main factor , which affects the system sensitivity .
-
以光纤视场折叠成像光谱仪成像原理为基础,研究原理样机的装调方法,建立装调流程,归纳出针对同轴折射式光学系统的装配、对准与精确调整方法。
Based on the engineering designing of fiber folded FOV imaging spectrometer prototype , study on the method of alignment , proposed the process of alignment of prototype . The paper summarized the assembly technology , mounting and evaluating methods for coaxial refraction optical system .
-
基于8253芯片的平板玻璃折射率CCD测量系统
Refractivity of Flat Glass CCD Measuring System Based on 8253
