钢丝绳直径

  • 网络wire rope diameter;drilling line
钢丝绳直径钢丝绳直径
  1. 自行设计制造的61250筐篮式成绳机与引进的81250筐篮式成绳机相比,缩小了捻距公比,捻制钢丝绳直径范围为18.5~65mm。

    Basket closer designed and made by oneself compared with imported 8 / 1250 basket closer , the lay pitch ratio shrunk . The wire rope diameter scope is 18.5 ~ 65 ?

  2. 对螺旋式预变形引入变形角α,对其各工艺参数运用数学方法进行回归分析,分别得出变形角、变形系数、变形器内径、变形器槽深与钢丝绳直径的经验公式。

    The conception of deformation angle of helix pre-former is introduced and process parameters are analyzed with math regression method . The experience formulas about the relationships of deformation angle , deformation coefficient , internal diameter and groove depth of former with wire rope diameter are obtained respectively .

  3. CCD技术测算提升钢丝绳直径的研究

    Study to Measuration for Diameter of Hoisting Steel Rope by CCD Technique

  4. 简述了目前国内摩擦提升钢丝绳直径检测的主要方法,并针对现状结合CCD技术,提出了一种新的提升钢丝绳直径CCD实时在线非接触式线径测量方法。

    The paper gives brief introduction to main domestic methods for measuring diameter of friction hoisting steel rope , and combining current status and CCD technique , offers a new method for CCD real-time on - line untouched measuration for rope diameter .

  5. 卷筒直径与钢丝绳直径匹配关系的研究

    A study on the maching relation between diameters of drums and cables

  6. 滑轮绳槽直径与钢丝绳直径匹配关系的探讨

    Inquiring into Match Relationship between Diameters of Pulley Groove and Wire Rope

  7. 大直径钢丝绳直径连续测量方法与装置

    Method and Apparatus for Measuring the Diameter of the Large Diameter Wire Ropes

  8. 解决钢丝绳直径减小的有效措施是使用钢芯钢丝绳。

    Effective measure solving the problem on decrease of rope is to use the steel wire rope with metal core .

  9. 本文在论述绞盘机卷筒主要参数&卷筒直径的确定原则的基础上,按优先数系提出卷筒直径系列后,研究了卷筒直径与钢丝绳直径的匹配关系。

    Diameter is the main parameter of the drums for forestry winches . Based on the established principles the matching relation between diameters of drums and cables has been studied .

  10. 通过分析影响精度的各个因素,得出了这样的结论:标定钢丝绳直径偏差和材料试验机存在的检定误差是主要原因。

    On the careful analysis of all the factors that affect the accuracy , I got the following conclusion : the main causes are from the diameter error of the calibrated wire line and the calibration error of the material tester .

  11. 多年来,起重机焊接卷筒壁厚的确定都是通过经验公式,即认为卷筒壁厚约等于钢丝绳直径,然后对卷筒分别进行强度和稳定性方面的校核。

    Over the years , the thickness of the welded drum is determined by the empirical formula , that the thickness of drum is equal to the diameter of the wire rope , then checking the strength and stability of the drum .

  12. 圆股钢丝绳钢丝直径计算方法介绍

    Calculation of Wire Diameter of Round Strand Wire Rope

  13. 35×7结构多层股钢丝绳钢丝直径比的计算

    Calculation of Steel Wire Diameters Ratio of 35 × 7 Structure Wire Rope with Multiplayer Strands

  14. 目前,厂矿企业仍沿用人工利用游标卡尺进行抽点检测法来测量提升钢丝绳的直径。

    At present , we use the vernier caliper to measure the diameter of steel rope by manual work .

  15. 结合电梯用钢丝绳绳芯直径过程控制,建立电梯用钢丝绳绳芯直径潜在失效模式及后果分析表。

    Combining with the course control of rope core diameters of steel wire ropes for elevators , the FMEA table is established .

  16. 对单股钢丝绳中心钢丝直径进行了计算,指出要保证绳径及捻制质量均合格,必须同时控制外层钢丝直径及中心钢线直径。

    Calculated diameter of core wire in wire rope with single strand , show to ensure quality of wire diameter and stranding all up to standard , diameter of outer wire and core wire must be controled at the same time .

  17. 本文第2、3部分介绍了驱动机的分类、张力比、钢丝绳、驱动轮直径和功率;对货车的类型、承载能力和斗箱容积进行论述。

    Chapters 2 and 3 introduce respectively the driver classification , tension ratio , steel cables , and driving wheel 's diameter and power capacity , and discuss carriage 's types , bearing capacity , and volumn .

  18. 介绍起重运输机械钢丝绳使用中滑轮直径、材料和槽型,钢丝绳的腐蚀和磨损,绳中钢丝强度对钢丝绳使用寿命的影响。

    To introduce the effect of the diameter , materials and groove type of pulley , the corrosion and abrasion of wire rope , the steel wire strength in rope on service life of wire rope during the use of wire rope for crane and transport .

  19. 分析表明钢丝绳为疲劳断裂,断裂原因是钢丝绳的直径选择不当,受力状态严重恶化造成的。

    Analysis shows that the fracture of the wire rope belongs to fatigue fracture , it is due to the inadequately choice of rope diameter and forced state being heavily deterioration .

  20. 通过国外挖掘机用多股镀锌钢丝绳结构、性能的解剖试验及钢丝绳中钢丝直径的计算总结出了这种钢丝绳的特点。

    Through test of construction and performance of multi - strands galvanized steel wire rope for imported excavator and calculation of diameter for steel wire , the characteristics of steel wire ropes are summarized .

  21. 特大跨径悬索桥对钢丝绳吊索的要求越来越高,要求吊索钢丝绳在保证直径和抗疲劳能力的前提下提高其破断拉力。

    This paper gives a niethod for determing the relatlonship between diameter and nominal breaking force of API steel wire rope .
