机座

压力容器机座焊缝开裂原因及应对措施

Crack Causes of the Engine Base of a Pressure Vessel and Countermeasures

轧机齿轮机座智能CAD系统

The intelligent CAD system for mill gear-box

脉冲TIG焊和自动MAG焊在电机机座上的应用

Application of pulse TIG and auto - MAG welding to motor base fabrication

对于电机机座图像，采用Hough变换方法，检测出图像包含的圆，进而求出同心度等公差。

For motor frame , circles in the matter brim was detected by means of Hough Transform and then concentricity tolerance was determined .

三段式机座600MW汽轮发电机的强度与振动

The Strength and Vibration for 600 MW Turbine-Generator with Three-Section Cone

600MW汽轮发电机定子机座及铁芯的动力特性分析

Dynamic characteristics analysis for the frame and core of 600 MW turbine generator

F4轧辊振纹频率为78Hz，是由机座水平系统共振造成的；

The frequency of F4 roller chatter mark is 78 Hz , which is caused by stand horizontal resonance vibration .

基于ANSYS软件，对PYQ202C平压压痕切线机机座进行了模态分析。

Based on the ANSYS , the model analysis has been made on the base of PYQ202C Press Machine .

介绍东方-日立型600MW汽轮发电机内外机座结构的定子铁心装配及定子装配有关工艺技术。

The paper introduces the relevant assembly process and technique for stator core & stator of Dongfang-Hitachi600MW turbo-generator .

YKK系列高压三相异步电动机（机座号355-710）是我公司为适应现代工业发展而设计开发的换代产品。

YKK series high-voltage three phase induction motor ( Frame No.355-710 ) is our company 's successor for adapting modern industry development .

Spar平台柱壳板格侧向压力极限载荷计算方法研究机壳与机座采用了平板钢性连接的全承载机壳结构，使结构更加简单，整机更加紧凑。

Research on calculation method for lateral pressure ultimate load on cylindrical shell panel of Spar platform hard tank The machine case and base are built with steel plate joint structure , simple and compact .

在热带钢连轧机设计及改造中采用WRS辊系作为下游机座可以增强机组的板形调控能力。

The ability of shape control could be improved by the application of WRS rolls as the downstream stands in the design and renovation of hot strip rolling .

Y系列（IP23）三相异步电动机技术条件（机座号160～280）

Specification for series Y ( IP23 ) three phase asynchronous motor ( H160 ~ 280mm )

东方电机股份有限公司生产的1000MW级核能发电机定子机座、铁心的固有频率、模态振型进行了三维有限元动力特性计算分析。

3D FEM analysis of natural frequency and modal shape on 1 000 MW nuclear generator stator frame and core are presented .

主机移放到机座后拆除运输底座，安装好线条板底板，将螺丝千斤顶按安装位置安放，将主机按坐标和标高就位到离地面100mm。

Remove the transport seat pads when the engine is shifted on the engine base , install the line plate baseboard , and place the screw jacks according to the installation position .

介绍了用I－DEAS程序的结构动态分析功能对水轮机座环进行动态分析，得到了座环的整体固有频率、振型及模态应力。

Dynamic analysis of stay ring for hydraulic turbine was made with I-DEAS dynamic analysis function . The nature frequency model shapes and model stresses of the whole stay ring were obtained .

H1400大型楔横轧机工作机座结构的结构及设计为满足大型轴类件生产和市场需求提供了设备保障。

The results show that the designed structure of the housing of a H1400 heavy cross wedge rolling mill provides effective equipment for meeting the market demand and rolling large-sized shaft-parts .

给出了定子的椭圆固有频率，定子铁心、机座、轴承座的振动幅值及定子机座的隔振系数，可供600MW汽轮发电机运行及大型汽轮发电机组的设计和制造参考。

Elliptical modal frequency of stator and vibration amplitude of core , frame and bearing house , and factor of isolated vibration are also given in the paper . These parameters are available for operation , design and manufacture of large turbine - generator .

按Denavit－Hartenberg方法，建立了多关节坐标测量机末端测头中心相对于机座参考坐标系的测量运动的数学模型。

By using homogenous coordinate transformation principle and Denavit Hartenberg analysis method , a measurement kinematics model and a error model for multi joint coordinate measuring machine , of which the movement of the probe center is relative to machine reference frame , is constructed .

水轮机座环和基础环平面打磨机的研制及应用

Development and Application of Grinding Machine For Stay and Discharge Rings

1号机座环变形情况分析及防止措施

Analysis and Prevention of Stay Ring Deformation of Number on Unit

如何正确地提高轧机工作机座的刚度

The correct method of raising the stiffness of roll mill stand

乙烯压缩机机座异常变形的分析及防治

Analysis and prevention on unusual deformation of ethylene compressor base box

其结构特点是：机座采用钢板压形焊接机座，滚动抱轴承结构；

Frame is a press-formed welded fabrication and hugging bearing structure ;

水轮机座环平面打磨设备的研制

Prepare of Grinding Equipment for Plane of Stay Ring of Turbine

大型汽轮发电机定子的电磁振动及机座减振研究

Magnetic vibration of large turbo - generator stators and its suppression

水轮机座环平面修磨设备的设计

Design of Grinding Device for Plane of Stay Ring of Turbine

中小型电机机座加工新工艺

A New Process for Frame Machining of Small and Medium Generator

一种滤元片材加工机，包括一机座平台；

A filtering sheet material piece processor comprises a base platform ;

空冷汽轮发电机定子机座的结构特点和装配工艺

Construction Feature and Assembly Technology of Large Capacity Air Cooled Generator
