过剩载流子

  • 网络excess carrier
过剩载流子过剩载流子
  1. 高温退火时NTDFZSi中产生的过剩载流子

    The Generation of Excess Carriers in NTDFZSi at High Temperature Annealing Process

  2. 纳米β-SiC薄膜过剩载流子衰减特性分析

    Excess Carriers Decay Behavior of Nanocrystalline β - SiC Thin Film

  3. 在IGBT关断过程中,pMOSFET将被开启,作为阳极短路结构起作用,从而使漂移区的过剩载流子迅速消失,IGBT快速关断。

    During the turning-off of the IGBT , the p-MOSFET is turned on , which provides a channel for the excessive carriers to flow out of the drift region and prevents the carriers from being injected into the drift region .

  4. 提出在低电压(小于07V)下,衬底电极的作用可近似等效成栅,然后依据电荷增量(非平衡过剩载流子)的方法,推导出该结构的IV特性方程。

    It is demonstrated that the substrate electrode can be regarded as a gate under the condition of low voltage supply ( < 0.7V ) . The equation of its I-V characteristics is then deduced according to the method of charge increment .

  5. 而且由于电场受到电阻场板的影响,使得过剩载流子能沿着一个更宽的通道流过漂移区,几乎消去了普通SOILIGBT由于衬偏造成的关断的第二阶段。

    At the same time , the electric field affected by the RFP makes the excessive carriers flow through a wider region , which almost eliminates the second phase of the turning-off of the SOI-LIGBT caused by the substrate bias .

  6. 该模型在Wirth-Rogers光电流模型的基础上,增加考虑了高注入对过剩载流子寿命的影响以及衬底(准中性区)电场的效应,这些效应对于高阻材料是不容忽视的。

    On the basis of Wirth-Rogers photocurrent models , the enhanced models include two additional effects as high injection effects on excess minority carrier lifetime and electric fields in the substrate ( quasi-neutral regions ) . These effects are most pronounced in high resistivity material .
