摇臂轴
- 网络rocker shaft;rocker arm shaft
-
转向齿扇摇臂轴断裂分析
Fracture Analysis on Veering Fan - shaped Rocker Shaft
-
气门摇臂轴油管接头
Valve rocker shaft oil pipe adapter DSS tubing joint
-
用ANSYS软件对柴油机摇臂轴座进行计算分析
Calculation and analysis of diesel engine rocker shaft bracket s using ANSYS software
-
变速比齿扇插齿加工的新型CNC系统汽车转向机摇臂轴精锻成形工艺
A New CNC System for Variable Ratio Sector Gear Shaping Precision Forging Technology for the Steering Sector Gear Shaft
-
在机座中安装转向摇臂轴和侧盖。
Install pitman shaft and side cover in the housing .
-
大客车转向机构摇臂轴的断裂分析
Failure Analysis of the Fixed - Pivot Shaft of a Coach Steering Mechanism
-
摇臂轴软氮化工艺研究
Study on the Lock Shaft Tufftriding Technique
-
汽车方向机摇臂轴断裂分析
Fracture analysis of steering gear rocker spindle
-
摇臂轴座精锻工艺及模具CAD/CAM研究应用
Rocker shaft bed of 280 diesel engine precise forging craft and mold CAD / CAM study application
-
螺栓穿过衬套被紧固,从而将摇臂轴固定在气缸盖上。
A bolt is fastened through the bush to thereby fix the rocker shaft on a cylinder head .
-
通过金相检验,扫描电镜等测试手段对转向齿扇摇臂轴断裂原因进行分析。
In this paper , the fracture of the veering fan-shaped rocker shaft was analyzed by means of metallograph and SEM .
-
数个油道形成在构成内燃机的阀驱动系统的一部分的摇臂轴的轴体中。
A plurality of oil passages are formed in a shaft body of a rocker shaft , which partially constitutes a valve drive system of an internal combustion engine .
-
介绍了热挤镦加热精整汽车转向机摇臂轴精锻成形工艺,对热挤镦的成形原理及变形过程进行了分析探讨。
The precision forging process for the steering sector gear shaft is discussed in the paper . The principle and the path of forming of the hot extruding and upsetting are also discussed .
-
这样的结构改善了摇臂轴的支撑刚度以及阀驱动系统的动力性能,并且减少了零件的数量和人工的工时数量。
This structure improves the support rigidity of the rocker shaft and the dynamic characteristics of the valve drive system , and reduces the number of components and the number of working man-hours .
-
最后,综合考虑了轮齿啮合刚度、摇臂轴扭转柔性及齿轮传动回差对差动平衡机构的影响,建立了能够比较完整地反映该机构动态特性的虚拟样机模型;
Finally , in consideration of the characteristics of the differential balance mechanism , a more accurate virtual prototype of the mechanism is established and the simulation is carried out in the software environment of ADAMS .
-
此外,轴肩过渡圆弧加工质量欠佳和结构刚性突变,产生较大的应力集中,在交变弯曲载荷作用下,导致摇臂轴多源双向弯曲疲劳断裂。
In addition , the stress concentration due to the imprecisely controlled machining and the sudden change of the stiffness in the structure , and the alternating load also contributed to the multi-source biaxial bending fatigue fracture of the fixed-pivot shaft .
-
本实用新型摇臂以销轴为定点,以摇臂的长度为定长来回摆动,形成一个弧形轨迹;
The rocker arm of the utility model swings back and forth by taking the pin as a fixed point and taking the length of the rocker arm as a fixed length , thus forming an arc path .
-
大型摇臂钻床滑座轴微机控制系统的研制
Design of a microcomputer-controlled system of the slide axis of a large-scale Rocker Arm Driller
