并五苯

  • 网络pentacene;TIPS pentacene;TIPS-PEN
并五苯并五苯
  1. 基于并五苯的光敏场效应晶体管的研究

    Photoresponsive Field-effect Transistors Based on Pentacene

  2. 在并五苯骨架上引入六个炔基扩大了分子共轭程度,从而使其带隙变的很窄,溶液中只有1.65eV。

    Introduction of six ethynyl-groups in the backbone of pentacene dramatically enlarge the conjugated systems , resulted in narrow band gaps in solution ( 1.65 eV ) .

  3. 并五苯分子在Ag(110)表面成膜过程中的结构研究

    In situ investigation of structural properties during formation of pentacene thin film on Ag ( 110 ) with MBE-LEED

  4. 本文介绍了如何利用物理气相沉积的技术制备并五苯晶体薄膜,并且进一步制备有机物并五苯场效应晶体管(OTFT)的方法。

    Methods of preparation of pentacene thin film by PVD and pentacene field effect transistor are reported .

  5. 并五苯有机薄膜晶体管电学性能研究

    Study on Electrical Characteristics of Pentacene Organic Thin Film Transistors

  6. 并五苯场效应发光管机理分析与场效应管制作

    Analysis and Fabrication of Light-emitting Field-effect Transistor Based on Pentacene

  7. 并五苯晶体与薄膜的同质异相体及其电子过程

    Polymorphs and Electronic Processes in the Crystalline and Thin Films of Pentacene

  8. 有机半导体材料并五苯薄膜的生长

    Growth for Thin Film Of Organic Semiconductor Pentacene

  9. 并五苯晶体薄膜的生长

    Physical Vapor Growth of Pentacene Crystal Thin Films

  10. 低电压并五苯薄膜场效应晶体管

    Low voltage pentacene thin film field-effect transistor

  11. 并五苯场效应晶体管的制备

    The Preparation of Pentacene Field Effect Transistor

  12. 利用以上测量方案我们对并五苯单晶材料的电阻率和接触电阻进行了测量。

    We measured the resistance and the contact resistance of the pentacene by using such method .

  13. 氟化并五苯分子光谱和激发态的密度泛函理论研究

    The study of density function theory on the molecular spectra and excited state of fluorid pentacene

  14. 一种廉价电极的并五苯场效应晶体管

    Pentacene field-effect transistors with cheap electrode

  15. 此外,我们讨论了并五苯薄膜的紫外-可见吸收光谱和光致发光光谱,分析了各个谱峰形成的原因。

    The optical behaviors , such as UV-Visible absorption and photoluminescence ( PL ) of pentacene film were also analyzed .

  16. 用物理气相沉积法在水平系统中生长有机半导体并五苯晶体薄膜。

    Physical vapor deposition in horizontal systems has been used for the growth of crystal thin-film of organic semiconductor pentacene .

  17. 以全蒸镀方法在真空室内一次性制备了正装结构的全有机并五苯薄膜场效应晶体管。

    Top-gate all organic thin-film field-effect transistors are fabricated one-off by fully-evaporation method without breaking vacuum , which has many advantages .

  18. 金原子加到并五苯上时,明显地改变了并五苯的跃迁方式,增加了可能的电子跃迁。

    Adding a gold atom to the pentacene obviously changes the transition nature of pentacene and results in the increase of possible transitions .

  19. 并五苯薄膜在生长温度为230℃,携带并五苯的保护气体流速为0.06m~3/h的条件下生长得最好。

    The best qualified pentacene film was obtained under the condition of the temperature at source zone of 230C and the velocity of nitrogen flow of 0.06m3/h .

  20. 发现在室温下,ⅠTO/pentacen界面没有可观察到的界面拆分,并且该结果与内建场的方向以及并五苯厚度无关。

    At room temperature , it was found that no interfacial dissociation could be observed , even changing the direction of built-in field or the thickness of Pentacene .

  21. 目前,有机薄膜晶体管的研究主要从实验和理论两个方面展开,在实验研究方面至今已经取得很大进展,据文献报道,用单晶并五苯作有源层的有机薄膜晶体管最大迁移率已经达到35cm~2/Vs。

    The studies on experiment have made great progress , according to report , the maximum mobility of the organic thin-film transistor hasreached35cm ~ 2 / Vs , whose active layer is pentacene of single crystal .
